Dorman 264-049 Engine Oil Pan

Engine Oil Pan Replacement for Select GM Vehicles

Dorman 264-049 is an aluminum engine oil pan engineered to match the original equipment pan on select Chevrolet Aveo, Chevrolet Aveo5, Pontiac G3, and Pontiac G3 Wave applications. It provides a direct replacement for vehicles in the 2007-2011 model years and includes a drain plug and dipstick port for service-friendly installation.

Key Features

• Aluminum construction with a natural finish
• OE-style replacement for select Chevrolet Aveo and Pontiac G3 applications
• Center sump, wet sump design
• Dipstick port included
• Drain plug included with 12 mm drain thread size
• 15 bolt holes for mounting
• Maximum capacity: 4.8
• Dimensions: 17.3 in. length, 12 in. maximum width, 6.562 in. maximum depth

Detailed Description

This Dorman engine oil pan is built for direct replacement on select 2007-2011 Chevrolet Aveo, 2009-2011 Chevrolet Aveo5, 2007-2010 Pontiac G3, and 2009 Pontiac G3 Wave models. Part number 264-049 is precision-engineered to match the original equipment pan shape and mounting layout, helping restore proper oil containment on the engine block. The aluminum design, center sump layout, and integrated dipstick port support a clean OE-style service replacement.

This part cross-references Spectra Premium GMP103A for the same application.

What It Helps Fix

• Oil pan leaks from a damaged or corroded pan
• Cracks or impact damage to the original oil pan
• Oil seepage around the drain area
• Improper sealing caused by a worn-out pan surface
• Service issues when the original pan is no longer reusable

Installation Notes and Tips

• Verify engine and vehicle fitment before installation on your Chevrolet Aveo, Aveo5, Pontiac G3, or G3 Wave.
• Gasket or seal is not included, so use the correct sealing components for the application.
• Installation hardware is not included.
• Inspect the mating surface, drain plug area, and bolt holes before assembly.
• Confirm clearance around the center sump and dipstick port during installation.

Quality Assurance

Dorman designs this oil pan as an OE-style replacement for specific vehicle applications, with dimensions and mounting points matched to the original part for reliable service fitment. Part number 264-049 is built for direct replacement use on the listed Chevrolet and Pontiac models.

• Fits 2009-2011 Chevrolet Aveo
• Fits 2009-2011 Chevrolet Aveo5
• Fits 2007-2010 Pontiac G3
• Fits 2009 Pontiac G3 Wave
