Dorman 598-701 Integrated Control Module
Dorman 598-701 Integrated Control Module
This Dorman integrated control module is a direct replacement for the original equipment unit used on select 2010 Dodge Ram 1500 and 2010 Dodge Ram 2500 applications. It is built to restore proper operation of electronic circuits controlled through the vehicle’s power distribution and control system.
- Direct replacement for the OE integrated control module
- Fits 2010 Dodge Ram 1500 and 2010 Dodge Ram 2500
- 11 black connectors with rectangular connector shape
- Plastic housing with 141 male blade and pin terminals
- Remanufactured totally integrated power module included in package contents
- Cross-references OE part numbers 731528 and 4692194AA for the same application
Detailed Product Overview
The Dorman 598-701 integrated control module is engineered for vehicles that rely on a centralized electronic module to manage multiple circuits. With 11 connectors, a black connector color, and a plastic housing measuring 9.5 inches long, 6 inches wide, and 7.5 inches high, this module matches the physical and electrical layout needed for specified Dodge Ram 1500 and Dodge Ram 2500 trucks. The Dorman 598-701 is a practical OE-style replacement when the original module no longer functions correctly.
Compatible With 2010 Dodge Ram 1500 and 2010 Dodge Ram 2500, this integrated control module supports restoration of factory circuit control in applications that use a totally integrated power module design. The part number 598-701 is also a useful reference when verifying interchange with OE numbers 731528 and 4692194AA.
Common Issues This Module May Resolve
- Loss of control to multiple body or electrical circuits
- Intermittent electrical operation caused by a failing integrated module
- No-response conditions in circuits routed through the power module
- Faults related to damaged internal module electronics
- Replacement needs after corrosion, heat damage, or connector-related failure
Installation Notes and Tips
Verify the vehicle’s original module part number, connector count, and terminal configuration before installation. This module uses 11 connectors, 141 terminals, and blade/pin terminal types, so connector alignment and secure seating are important during replacement. Confirm fitment for the exact Ram 1500 or Ram 2500 application before service, and follow factory diagnostic and programming procedures where required by the vehicle.
Quality Assurance
Dorman supplies this integrated control module as a remanufactured replacement part for specified OE applications. It is intended to restore proper function in the electronic circuits controlled by the original module design.
